A.Feeding part
  Vacuum adsorption lead - edge paper feeding, with frequency conversion control of air volume, ensuring stable and accurate paper
feeding.
  Automatic zero - return system for the entire machine, storing common orders, enabling quick order change and easy operation.Dust removal device and electrostatic brush can remove paper dust on the surface of the cardboard, improving print quality.
Left and right baffles and the rear bafle are computer -controlled, with a precise guiding mechanism for smooth displacement, and a side shooting function.
Optional: Servo lead edge, pressure - free lead edge system.

B.Printing part
Full - process vacuum adsorption, combined with a ceramic paper - feeding wheel transfer system.
the damper switch according to the length of the cardboard.
Variable frequency adjustment of adsorption wind force; can also automatically adjust
closed - ype doctor blade matched with ceramic anilox roller, achieving high - dot - precision printing, uniform force on the doctor blade, simple adjustment and maintenance.
Pneumatic double - diaphragm pump, featuring quick cleaning function, stable ink supply and circulation, and simple operation &maintenance.
Quick - change rubber roller and anilox roller device, equipped with a quick - change bracket.Printing plate cleaning memory and automatic reset system.
Optional: Tit correction printing roler; tilt errors during plate mounting can be quickly corrected on the printing roller, making plate hanging convenient and quick.

C.Die-cutting part
Equipped with imported quick - change polyurethane rubber pads, easy to replace, with a one - way clutch for linear speed compensation function. It can ensure that the die - cut cardboard remains completely consistent after the rubber pads are worn.The mechanical spiral of the die - cutting rubber pad roller enables automatic left - and - right transverse movement (±20mm), preventing repeated knife marks on the cut and prolonging the service life of the rubber pad.
The gap between the rubber pad roller and the die - cutting roller is pneumatically controlled. During normal paper feeding, the rubber pad roller descends to the working position; when paper feeding stops, the rubber pad roller automatically rises.
Rubber pad corection mechanism, increasing the number of uses of the rubber pad and reducing consumption.
Awaste paper conveying device is installed at the bottom of the die - cutting unit, transferring paper scraps outside the equipment for easy cleaning.
