1. ES-B Shaftless Electrical Mill Roll Stand

    Symmetric structure for non-stop paper change; electric control for paper lifting/clamping/centering; pneumatic tension + braking; expansion-type paper clamp.
2. SF-320 Adsorption Type Single Facer Machine

    Negative pressure design (uniform corrugation/gluing); corrugated roller (48CrMo, HRC58, medium-frequency quenching + hard chrome plating); airbag pressure control; electric glue adjustment; easy-clean glue system.
3. GM-E Gluer Machine

    Cast iron frame (stability); independent frequency conversion motors per layer; PLC-controlled coating gap; stainless steel glue tank (auto circulation); dynamic-balanced glue rollers (glue saving).
4. SM-F Heavy Double Facer Machine

    S-shaped steam flow (high heat efficiency); pneumatic pressure plate + roller pressing; auto deviation correction for belts; 45KW variable-frequency main motor (energy-saving).
5. BFY Thin Blade Slitting Machine

    Electric knife adjustment (synchronous motor); switchable line types; tungsten alloy blades (≥8 million meters service life); imported synchronous belt transmission.
6. SC-B120 NC Cutter Machine

    High-rigidity ground gears (burr-free cutting); AC servo drive; auto fault detection + 999-order storage; oil pump circulation lubrication.
7. DMT Right Angle Stacking Machine

    Deceleration stacking + electric transverse conveying; wide conveyor belt; switch control (stacking count/height).
8. Transmission & Lubrication

    40Cr gears (HRC55-60, grade 6 precision); keyless couplings (gap elimination); continuous circulating oil supply (mechanical double pump); closed spray lubrication.
Component Features
    1. ES-B Shaftless Electrical Mill Roll Stand. Symmetric structure enables non-stop paper change; electric control for paper lifting, clamping and centering; pneumatic tension and braking; expansion-type paper clamping head.
    2. SF-320 Adsorption Type Single Facer Machine. Negative pressure design ensures uniform corrugation forming and gluing; corrugated roller (48CrMo, HRC58, medium-frequency quenching + hard chrome plating); airbag pressure control; electric glue quantity adjustment; easy-to-clean glue system.
    3. GM-E Gluer Machine.Cast iron frame for stable operation; independent variable-frequency motor per layer; PLC-controlled coating gap; stainless steel glue tank with automatic circulation; dynamic-balanced glue rollers (reduces glue waste).
    4.SM-F Heavy Double Facer Machine. S-shaped steam flow in heating plates (high thermal efficiency); pneumatic pressure plate + roller-type pressing; automatic deviation correction for upper/lower belts; 45KW variable-frequency main motor (energy-saving).
    5.BFY Thin Blade Slitting Machine. Synchronous motor-driven electric knife adjustment; switchable line types (convex-concave/convex-flat); tungsten alloy blades (service life ≥8 million meters); imported synchronous belt transmission.
    6.SC-B120 NC Cutter Machine.High-rigidity ground gears (burr-free cutting); AC servo drive; automatic fault detection + 999-order storage; oil pump circulation lubrication.
   7. DMT Right Angle Stacking Machine Deceleration stacking + electric transverse conveying; wide conveyor belt; switch control (by stacking count or height).
    8.Transmission & Lubrication.40Cr gears (HRC55-60, grade 6 precision); keyless couplings (eliminates gaps); continuous circulating oil supply (mechanical double pump); closed spray lubrication for transmission components.
